GYTS-62~72Xn Optic Cable is Loose sleeve stranded lightly armored optical cable
GYTS-62~72Xn Optic Cable Product Overview
GYTS fiber optic cable is outdoor fiber cable with corrugated steel tape armored. Suitable for duct and direct buried application with fiber counts from 2 cores to 432 cores for both singlemode and multimode.
The structure of GYTS fiber optic cable is that a 250μm optical fiber is sleeved into a loose tube made of high-modulus material, and the loose tube is filled with a waterproof compound. In the center of the core is a metal reinforcing core, and for some core cables, 'n laag poliëtileen (PE) is squeezed out of the metal reinforcing core. Die los buis (en vulstou) word om die sentrale versterkende kern gedraai om 'n kompakte en afgeronde kern te vorm, en die gapings in die kern is gevul met waterblokkering. Double-sided plastic-coated steel tape (PSP) is longitudinally wrapped and extruded into a polyethylene sheath to form a cable.
GYTS-62~72Xn Optic Cable Product Pictures
GYTS-62~72Xn Optic Cable Product Specifications
| Veseloptiese kabelmodel (In stappe met 2 vesel) | Aantal vesels | Aantal omhulsels | Aantal vul toue | Verwysingskabelgewig (kg/km. |
Trekkrag word toegelaat Langtermyn/korttermyn (N) |
Toelaatbare muurskrag Langtermyn/korttermyn (N/100mm) |
Buig radius Staties/dinamies (mm) |
|
| GYTS-2~6Xn | 2~6 | 1 | 4 | 96 | 600/1500 | 300/1000 | 10D/20D | |
| GYTS-8~12Xn | 8~12 | 2 | 3 | 96 | ||||
| GYTS-14~18Xn | 14~18 | 3 | 2 | 96 | ||||
| GYTS-20~24Xn | 20~24 | 4 | 1 | 96 | ||||
| GYTS-26~30Xn | 26~30 | 5 | 0 | 96 | ||||
| GYTS-32~36Xn | 32~36 | 6 | 0 | 105 | ||||
| GYTS-38~48Xn | 38~48 | 4 | 1 | 111 | ||||
| GYTS-50~60Xn | 50~60 | 5 | 0 | 111 | ||||
| GYTS-62~72Xn | 62~72 | 6 | 0 | 138 | ||||
| GYTS-74~84Xn | 74~84 | 7 | 1 | 168 | ||||
| GYTS-86~96Xn | 86~96 | 8 | 0 | 168 | ||||
| GYTS-98~108Xn | 98~108 | 9 | 1 | 195 | ||||
| GYTS-110~120Xn | 110~120 | 10 | 0 | 195 | ||||
| GYTS-122~132Xn | 122~ 132 | 11 | 1 | 228 | ||||
| GYTS-134~144Xn | 134~ 144 | 12 | 0 | 228 | ||||
| GYTS-146~216Xn | 146~ 216 | 13~18 | 5~ 0 | 228 | ||||
| GYTS-288Xn | 288 | 24 | 0 | 283 | ||||
| Vesel tipe | attenuation （+20℃） | bandwydte | Numeriese diafragma | Veseloptiese kabelafsnipgolflengte | ||||
| @850nm | @1300nm | @1310nm | @1550nm | @850nm | @1300nm | |||
| G.652 | - | - | ≤0.36db/km | ≤0.22db/km | - | - | - | ≤1260nm |
| G.655 | - | - | ≤0.40db/km | ≤0.23dB/km | - | - | - | ≤1450nm |
| 50/125µm | ≤3.0db/km | ≤1.0db/km | - | - | ≥500MHz · km | ≥500MHz · km | 0.200± 0,015 reeds | - |
| 62.5/125µm | ≤3.3db/km | ≤1.0db/km | - | - | ≥200MHz · km | ≥500MHz · km | 0.275± 0,015 reeds | - |
GYTS-62~72Xn Optic Cable Product Features
- Het baie goeie meganiese eienskappe en temperatuurkenmerke
- Die los buismateriaal self het goeie hidrolise -weerstand en hoë sterkte
- The tube is filled with a special ointment to protect the optical fiber
- The specially designed tight cable structure effectively prevents the casing from retracting
- Goeie kompressie weerstand en sagtheid
- The PE sheath has very good resistance to UV radiation
- The following measures are taken to ensure the waterproof performance of the fiber optic cable
- Single wire center reinforcing core
- The loose tube is filled with a special waterproofing compound
- Full core filling
- Double-sided plastic-coated steel tape armor
GYTS-62~72Xn Optic Cable Product and More Optic Cables
- GJXH butterfly hybrid cable
- GDVV/GDHH/GDJH type hybrid cable
- Hybrid kabel vir toegangsnetwerk (Gdta53)
- Baster optiese kabel (Gdts) vir toegangsnetwerke
- Hibriede kabel vir toegangsnetwerke (Gdta)
- Skeletvesel optiese lint A-omhulde veseloptiese kabel (Wederkerig)
- Middelste buis y-omhulde anti-knalige veseloptiese kabel (Gyxty)
- Middelste buis omhulde veseloptiese kabel met anti-knalie (Gydxts)
- In-buis omhulde anti-knalige veseloptiese kabel (Gyxts)
- Middel 53 Omhulde anti-knalige kabel(Gyxty53)
- Los buistipe enkel dun ronde staal draad gepantserde optiese kabel(Gyxta33)
- Veselbundel middelbuis omhulde anti-knalige veseloptiese kabel (Gysxts)
- Veselbundel lugblaas mikro -kabel (Gycfsy)
- Nie-metaal-sentrale buis weerlig en die beskerming van die knaagdierbeskerming(Gyqfxty)
- Nie-metaal-sentrale buis 73 Omhulde liggewig weerlig en optiese veselkabel van die vesel (Gyqfxty73)
- Flame retardant fiber optic cable for central tube coal mine (MGXTW)
- Flame retardant optical cable for loose sleeve stranded coal mine (MGTS)
- Stranded Non-Metallic Airblowing Fiber Optic Cable (JET)
- Miniature Non-Metallic Airblown Fiber Optic Cable (JET)
- All-dielectric self-supporting cable (ADSS)
- Fire Resistant Fiber Optic Cable (GJFZY53-FR)
- Loose sleeve stranded dry fiber optic cable (DCFA)
- Figuur 8 Fiber Optic Cable (GYTC8A)
- Central Tube Light Armoured Fiber Optic Ribbon Cable (GYDXTW)
- Central tube flame retardant fiber optic cable (GYXTZW)
- Central tube type non-metallic non-armoured fiber optic cable (GYFXY)
- Central tube unarmoured fiber optic cable (GYXY)
- Central Tube Light Armoured Fiber Optic Cable (GYXS/GYXTW)
- Loose sleeve stranded light armored fiber strip cable (GYDTS)
- Gestrande los baadjie Ongewerpte veseloptiese kabel (GYDTA)
- Gestrande los baadjie Nie-metaalversterkte kern nie-bewoer vlamvertragende veseloptiese kabel (Gyftzy)
- Los mou gestrand versterkte kern gepantserde vlamvertrager optiese kabel(Gytza53)
- Los mou gestrand nie-metaalversterkte kern gepantserde vlamvertrager veseloptiese kabel (Gyftza53)
- Gestrande vlamvertragende veseloptiese kabel (Gytzs)
- Gestrande los baadjie nie-bewoer vlam retardante vesel optiese kabel (Gytza)
- Gestrande los mou nie-metaalversterkte kern gepantserde veseloptiese kabel (CYFTA53)
- Gestrande nie-metaalversterkende versterkende optiese veselkabel (CYFTY53)
- Gestrande los baadjie nie-metaalversterkte kern sonder bewapening van veseloptiese kabel (SAAM)
- Los mou gestrand nie-metaalversterkte kernoptiese kabel (Gyhty)
- Gestrande los baadjie nie-metaalversterkte kern sonder bewapening van veseloptiese kabel (Niggie)
- Los mou gestrand enkel dun dun ronde staal draad gepantserde vesel optiese kabel (Gyta53+33)
- Los mou gestrand versterkte gepantserde veseloptiese kabel(Gyta53)
- Los mou gestrand gewone gepantserde veseloptiese kabel(Gyty53)
- Los mou gestrand ligte gepantserde veseloptiese kabel (Konsonant)
- Gestrande los baadjie Ongewerpte veseloptiese kabel (Beklemtoon)
GYTS-62~72Xn Optic Cable Product Applications
- Long-distance communication and Local communication
- Especially suitable for occasions with high requirements for moisture-proof and rodent-proof
GYTS-62~72Xn Optic Cable Product Structure
