GYFTA53-110~120Xn Optic Cable is Loose-tube stranded non-metallic reinforced core armored optical cable. Applicable: Suspended
GYFTA53-110~120Xn Optic Cable Product Overview
The structure of GYFTA53 optical cable consists of a 250µm optical fiber housed in a loose tube made of high-modulus material, with waterproof compounds filling the inside of the tube. The center of the cable core features a non-metallic reinforcement core (चालि), and for certain fiber counts, a layer of polyethylene (PE) is additionally extruded around the non-metallic reinforcement core. The loose tube (and filling rope) is twisted around the central reinforcement core to form a compact and round cable core, with the gaps inside the core filled with water-blocking filler. A layer of polyethylene inner sheath is extruded after wrapping with aluminum tape (एपीएल), and a polyethylene outer sheath is formed after wrapping with double-sided coated steel tape (बैज).
This comprehensive structure of the GYFTA53 optical cable ensures durability, resistance to water damage, mechanical strength, and protection against external factors. With these features, the cable enables reliable transmission of data through the optical fibers, making it suitable for various telecommunications and networking applications.
GYFTA53-110~120Xn Optic Cable Product Pictures
GYFTA53-110~120Xn Optic Cable Product Specifications
| Fiber cable model (in increments of 2 फाइबर) | Number of optical fiber tubes | Number of sleeves | Number of filling ropes | Reference optical cable weight (kg/km) | Allowable tensile force Long-term/short-term (एन) | Allowable crushing force long term/short term (N / 100mm) | Bending radius static/dynamic (mm) | |
| GYFTA53-2~6Xn | 2~6 | 1 | 7 | 228 | 1000/3000 | 1000/3000 | 12.5D / 25D | |
| GYFTA53-8~12Xn | 8~१२ | 2 | 6 | 228 | ||||
| GYFTA53-14~18Xn | 14~१८ | 3 | 5 | 228 | ||||
| GYFTA53-20~24Xn | 20~ २४ | 4 | 4 | 228 | ||||
| GYFTA53-26~30Xn | 26~३० | 5 | 3 | 228 | ||||
| GYFTA53-32~36Xn | 32~३६ | 6 | 2 | 228 | ||||
| GYFTA53-38~42Xn | 38~ 42 | 7 | 1 | 228 | ||||
| GYFTA53-44~48Xn | 44~ ४८ | 8 | 0 | 228 | ||||
| GYFTA53-50~60Xn | 50~60 | 5 | 3 | 240 | ||||
| GYFTA53-62~72Xn | 62~७२ | 6 | 2 | 240 | ||||
| GYFTA53-74~84Xn | 74~ ८४ | 7 | 1 | 240 | ||||
| GYFTA53-86~96Xn | 86~96 | 8 | 0 | 240 | ||||
| GYFTA53-98~108Xn | 98~१०८ | 9 | 1 | 276 | ||||
| GYFTA53-110~120Xn | 110~१२० | 10 | 0 | 276 | ||||
| GYFTA53-122~132Xn | 122~१३२ | 11 | 1 | 326 | ||||
| GYFTA53-134~144Xn | 134~१४४ | 12 | 0 | 326 | ||||
| Fiber optic type | Attenuation （+20℃） | ब्यान्डविथ | Numerical aperture | Optical fiber cutoff wavelength | ||||
| @ 850NM | @ 1300NM | @ 1310NM | @ 1550NM | @ 850NM | @ 1300NM | |||
| G.652 | - | - | ≤ 0.36db / KM | ≤ 0.22DB / KM | - | - | - | ≤1260NM |
| G.655 | - | - | ≤ 0.40DB / KM | ≤ 0.23DB / KM | - | - | - | ≤1450nm |
| 50/125µm | ≤3.3DB / KM | ≤1.2dB/km | - | - | ≥0000zz · · · · | ≥0000zz · · · · | 0.200± 0.015 पहिले नै | - |
| 62.5/125µm | ≤3.5dB/km | ≤1.2dB/km | - | - | ≥200mhz · किम | ≥0000zz · · · · | 0.275± 0.015 पहिले नै | - |
GYFTA53-110~120Xn Optic Cable Product Features
- It has excellent mechanical properties and temperature characteristics.
- The loose tube material has good hydrolysis resistance and high strength.
- Special oil paste fills the tube, providing critical protection for the optical fibers.
- It has good compressive strength and flexibility.
- The following measures are taken to ensure the waterproof performance of the cable:
- A single non-metallic central reinforcement core
- The loose tube is filled with a special waterproof compound
- Complete core filling- Plastic-coated aluminum tape (एपीएल) नमी बाधा
- डबल-पक्षीय प्लास्टिक-कोटेड स्टील टेप (बैज) to enhance the cable’s moisture resistance
- Good water-blocking materials to prevent longitudinal water ingress in the cable.
GYFTA53-110~120Xn Optic Cable Product and More Optic Cables
Loose-tube layer-stranded non-metal reinforced core ordinary armored optical cable (Cyfty53)
Loose-tube layer-stranded non-metal reinforced core unarmored optical cable (सँगै)
Loose-tube layer-stranded non-metal reinforced core optical cable (जार)
Loose-tube layer-stranded non-metal reinforced core unarmored optical cable (भान्ज दाई)
Loose-tube layer-stranded single fine steel wire armored optical cable (GyTa53 33)
Loose-tube layer-stranded reinforced armored optical cable (GyTa53)
Loose-tube layer-stranded ordinary armored optical cable (Gyty53)
Loose-tube layer-stranded light armored optical cable (व्यन्जन)
Central tube type Y jacket rodent-proof optical cable (GYXTY)
Central tube type S jacket fiber ribbon rodent-proof optical cable (GYDXTS)
Central tube type S jacket rodent-proof optical cable (GYXTS)
Central tube type 53 jacket rodent-proof optical cable (GYXTY53)
Loose-tube central tube type single fine steel wire armored optical cable (GYXTA33)
Optical fiber bundle central tube type S jacket rodent-proof optical cable (GYSXTS)
GYFTA53-110~120Xn Optic Cable Product Applications
- Frequent lightning area and anti electric field : The subway, tunnel
- Duct and direct buried application
- Harsh environment
- Adopted to Outdoor distribution.
- Suitable for aerial duct and buried method.
- Long distance and local area network communication.
GYFTA53-110~120Xn Optic Cable Product Structure
