Description
Huawei HG8247H FTTH is optical terminal Unit with 4GE + 2VOICE + WIFI + CATV firmware SIP
Huawei HG8247H FTTH Product Overview
Huawei HG8247H FTTH is a routing-type ONT used in the Huawei all-optical access solution. It uses GPON technology to provide ultra-broadband access for users.
This model provides 4 GE+2 POTS+1 USB+1 RF+2.4G WiFi(4 GE Ethernet ports,2 POTS ports, 1 USB port, 1 RF port and 1 2.4G WiFi port). High-performance forwarding provides voice, data, CATV and HD video services, and provides users with ideal terminal solutions and future-oriented service support capabilities.
Huawei HG8247H FTTH Product Pictures
Huawei HG8247H FTTH Specifications
| Brand | Huawei |
| Model | HG8247H |
| Ports | 2POTS + 4GE + CATV + Wi-Fi + USB |
| Weight | 400g |
| Dimension | 220 mm x 160 mm x 32 mm |
| Power Adapter Input | 100–240 V AC, 50/60 Hz |
| System Power Supply | 11–14 V DC, 2 A |
| Static power consumption | 7.5w |
| Maximum power consumption | 18w |
| Operating temperature | 0°C to 40°C |
| Operating humidity | 5% RH to 95% RH (non-condensing) |
Huawei HG8247H FTTH and more models
| HG8010 | EPON ONT, 1*Lan English Firmware |
| HG8310 | EPON ONT, 1*Lan English Firmware |
| HG8110 | EPON ONT, 1*LAN + 1 * Voĉo English Firmware |
| HG8120 | EPON ONT, 2*LAN + 1 * Voĉo English Firmware |
| HG8240 | EPON ONT, 4*Lan + 2 * Voĉo English Firmware |
| HG8346R | EPON ONT, 4*Lan + 2 * Voĉo + WIFI English Firmware |
| HG8245H | EPON ONT, 4*Lan + 2 * Voĉo + WIFI English Firmware |
| HG8310M | GPON ONT, 1*Lan English Firmware |
| HG8010 / HG8010C | GPON ONT, 1*Lan English Firmware |
| HG8311 / HG8110 / HG8110F | GPON ONT, 1*LAN + 1 * VOĈO English firmware SIP |
| HG8120C / HG8120F / HG8120 / HG8321 / HG8321R | GPON ONT, 2Lan + VOĈO English firmware SIP |
| HG8340M / HG8540 / HG8040 | GPON ONT, 4FE English firmware SIP |
| HG8342 / HG8342R / HG8342M / HG8240 | GPON ONT, 4FE + 2VOICE English firmware SIP |
| HG8240 / HG8240H | GPON ONT, 4GE + 2VOICE English firmware SIP |
| HG8345R internal antenna | GPON ONT, 4FE + WIFI (internal antenna)English firmware SIP |
| HG8345R external antenna | GPON ONT, 4FE + WIFI (external antenna)English firmware SIP |
| HG8546M | GPON ONT, 1GE + 3FE + VOĈO + WIFI, English firmware SIP |
| HG8346M / HG8245A / HG8346R | GPON ONT, 4FE + 2VOICE + WIFI (internal antenna)English firmware SIP |
| HG8346R external antenna | GPON ONT, 4FE + 2VOICE + WIFI (external antenna)English firmware SIP |
| HG8245C2 | GPON ONT, 2GE + 2FE + 2VOICE + WIFI English firmware SIP |
| HG8245 external antenna | GPON ONT, 4GE + 2VOICE + WIFI ( external antenna)nigra colours English SIP |
| HG8245H | GPON ONT, 4GE + 2VOICE + WIFI English firmware SIP ONT |
| HG8247H | GPON / EPON ONT, 4GE + 2VOICE + WIFI + CATV English firmware SIP |
Huawei HG8247H FTTH Product Applications
