Deskripsyon
Huawei AirEngine 9703-H is a high-performance wireless Access Controller (AC) ak 1 x 100G optical/2 x 40G optical/4 x 25G optical/8 x 10G optical/(1 x 40G optical + 4 x 10G optical) + 4 x 25G optical +4 x 10G optical + 8 x GE Combo*
Huawei AirEngine 9703-H Product Overview
Huawei AirEngine 9703-H is a next-generation high-performance access controller designed for large enterprise campuses, branches, and campuses. The access controller can manage up to 20,480 APs and have a forwarding capability of up to 160 Gbit/s. The number of wireless access points can be flexibly configured and has good scalability. With Huawei’s full range of 802.11n, 802.11ak, 802.11rach, and 802.11be wireless access points, you can build application environments such as large-scale campus networks, enterprise office networks, wireless metro networks, and hotspot coverage.
Huawei AirEngine 9703-H Product Pictures
Huawei AirEngine 9703-H Product Specifications
| Paramèt | AirEngine 9703-H |
| Pò | 1 x 100G optical/2 x 40G optical/4 x 25G optical/8 x 10G optical/(1 x 40G optical + 4 x 10G optical) + 4 x 25G optical +4 x 10G optical + 8 x GE Combo* |
| * indicate that the port combinations are mutually exclusive. Cards can be inserted into the backplane to expand interfaces in the future. | |
| Ekipman pou pouvwa | AC or DC power adapter |
| Kapasite Transmisyon | 160 Gbps |
| Maximum Number of Managed APs | 20480 |
| Maximum Number of Access Users | 307200 |
| AP-AC Networking | Kouch 2 or Layer 3 networking |
| Forwarding Mode | Direct forwarding or tunnel forwarding |
| AC Active/Standby Mode | 1 + 1 HSB or N + 1 backup |
| Radio Protocol | 802.11a/b/g/n/ac/ax/be |
Huawei AirEngine 9703-H Product Features
- Provide various high-rate interfaces such as 100G/40G/25G/10G optical ports and GE Combo ports, supporting up to 160Gbps forwarding performance.
- Balanse chaj pandan itinérance entelijan: The load balancing algorithm is used to perform load balancing detection on APsafter STAs roam, and adjust the STA load on each AP accordingly to improve network stability.
- Intelligent DFA technology: The dynamic frequency assignment (DFA) algorithm is used to automatically detect adjacent-channel and co-channel interference, and identify any 2.4 GHz redundant radio. Through automatic inter-AP negotiation, the redundant radio is automatically switched to another mode (dual-5G AP models support 2.4G-to-5G switchover) or is disabled to reduce 2.4 GHz co-channel interference and increase the system capacity.
- Intelligent conflict optimization technology: The dynamic enhanced distributed channel access (EDCA) ak algorithm orè lè yo itilize pou planifye tan okipasyon chanèl la ak priyorite sèvis chak itilizatè.. This ensures thateach user is assigned relatively equal time for using channel resources and user services are scheduled in an orderly manner, amelyore efikasite pwosesis sèvis ak eksperyans itilizatè.
Huawei AirEngine 9703-H Product and More Models
AirEngine 9703-H Access Controller
AirEngine 9703-S Access Controller
AirEngine 9700-M1 Access Controller
AirEngine 9701-L Access Controller
Huawei AirEngine 9703-H Product Applications
