Huawei SSN1SLD4A(S-4.1,LC) Board is Finished board unit-OptiX OSN 3500-SSN1SLD4A20-2xSTM-4 optical interface board.
Huawei SSN1SLD4A(S-4.1,LC) Board Product Overview
Huawei SSN1SLD4A(S-4.1,LC) Board is 2xSTM-4 optical interface board (SLD4 for short) and realizes the reception and transmission of 2 STM-4 optical signals, completing the optical-to-electrical conversion of STM-4 signals, the extraction and insertion of overhead bytes, and reports the generated signals Alarm. Huawei SLD4A single board consists of clock data recovery module, SDH overhead processing module, logic control module and power module group
Huawei SSN1SLD4A(S-4.1,LC) Gambar Produk Papan
Huawei SSN1SLD4A(S-4.1,LC) Spesifikasi Produk Papan
| Merek | Huawei |
| Nomor Bagian Produk | 3053176 |
| Model | Huawei SSN1SLD4A(S-4.1,LC) |
| Keterangan | 2xSTM-4 Papan Antarmuka Optik |
| Atribut Perangkat Lunak dan Perangkat Keras | Perangkat keras |
| UOM | buah |
| Dimensi Bersih(D*W*T mm) | 25*262*265 |
| Kekuatan Khas(W) | 17 |
| Daftar Harga(Rp) | $10129.00Peringatan Harga |
| Kategori Diskon | Papan Bersama Seri OptiX OSN |
| Lini Produk | Jaringan |
| Sub Keluarga Produk | MSTP |
Huawei SSN1SLD4A(S-4.1,LC) Spesifikasi Produk Papan
- 2xSTM-4 Papan Antarmuka Optik
- Berlaku untuk Huawei OSN 1500B, OSN 2500, OSN 3500 and OSN 7500 to transmit and receive 2xSTM-4 optical signals, at 2~15km.
- Mendukung deteksi dan permintaan informasi tentang modul optik.
- Support the ALS function. The optical interface supports setting of the on/off state of a laser.
- Support two-fiber ring MSP, four-fiber ring MSP, linear MSP, SNCP, SNCTP, and SNCMP protection schemes.
- Support fiber-shared MSP and SNCP, processes four sets of K bytes.
- Support the in-service loading of the FPGA.
- Mendukung peningkatan perangkat lunak papan tanpa mempengaruhi layanan.
- Mendukung fungsi tekan untuk mengumpulkan dalam pengumpulan data kesalahan.
Huawei SSN1SLD4A(S-4.1,LC) Board Specific Models
| SSN1SLD4A(S-4.1,LC) | Finished board unit-OptiX OSN 3500-SSN1SLD4A20-2xSTM-4 optical interface board (S-4.1, LC) |
| SSN1SLD4A(L-4.1,LC) | Finished board unit-OptiX OSN 3500-SSN1SLD4A21-2xSTM-4 optical interface board (L-4.1, LC) |
| SSN1SLD4A(L-4.2,LC) | Finished board unit-OptiX OSN 3500-SSN1SLD4A22-2xSTM-4 optical interface board (L-4.2, LC) |
- OSN3500 SLD4A single board: The insertable slots of the SLD4A single board are related to the cross-connect capacity of the device. When the crossover capacity is 200Gbit/s, the SLD4A board can be inserted in slots 1~8, 11~17 of the subrack.
- OSN1500 SLD4A board: Ukuran papan: 25.4mm (lebar) x 235.2mm (kedalaman) x 261,4 mm (tinggi) berat: 0.6kg.
Huawei SSN1SLD4A(S-4.1,LC) Board Product Application
