Huawei S12708 Switch

SKU: Huawei S12708 Switch Category: Tags: ,

Description

Huawei S12708 Switch  features  4.88/16.08 Tbit/s Switching Capacity 12.32/44.96 Tbit/s Packet Forwarding Rate 2 MPU Slots 4 SFU Slots 6 Service Card Slots

Huawei S12708 Switch Product Overview

Huawei S12708 Switch is designed for next-generation campus networks, which uses a fully programmable architecture to meet fast-changing service needs. Huawei S12708 Switch allows new services to be flexibly and quickly provisioned in six months. Huawei S12708 Switch provides high-performance Layer 2/Layer3 switching services, supports millions of hardware entries, and can meet campus network evolution over the next 10 years. Huawei S12708 Switch has built-in large-capacity WLAN AC functionalities, achieving wired and wireless convergence and eliminating the capacity bottleneck of ACs.

Huawei S12708 Switch Product Pictures

Huawei S12708 Switch Product Specifications

Item S12704 S12708 S12710 S12712
Switching capacity 4.88Tbps/16.08*Tbps 12.32Tbps/44.96*Tbps 13.12Tbps/38.56*Tbps 17.44Tbps/44.96*Tbps
Packet forwarding rate 3, 120Mpps/4, 560*Mpps 6, 240Mpps/30, 240*Mpps 7, 440Mpps/11, 040*Mpps 9, 120Mpps/30, 240*Mpps
MPU slots 2 2 2 2
SFU slots 2 4 4 (2 integrated in MPU) 4
Service card slots 4 8 10 12
Fan slots 2 4 4 5
Buffer size 200ms buffer each port
Redundancy design MPUs, SFUs, power supplies, and fan modules
CSS2 1+N backup of MPUs in a cluster
Up to 1.92 Tbit/s cluster bandwidth, 4 μs inter-chassis transmission latency
Dimensions (H x W x D in mm) 441.7x442x489, 10U 663.95x442x489, 15U 663.95x442x489, 15U 841.75x442x489, 19U
Weight (empty chassis) 24.5kg 42kg 28.6kg 64kg
Operating voltage DC:–40V~–72V
AC:90V~290V
Maximum power consumption of the entire equipment ≤2200W ≤4400W ≤4400W ≤6600W

Huawei S12708 Switch Product Features

OPS

Open Programmability System (OPS) is an open programmable system based on the Python language. IT administrators can program the O&M functions of a switch through Python scripts to quickly innovate functions and implement intelligent O&M.

Big data security collaboration

Agile switches use NetStream to collect campus network data and then report such data to the Huawei Cybersecurity Intelligence System (CIS). The purposes of doing so are to detect network security threats, display the security posture across the entire network, and enable automated or manual response to security threats. The CIS delivers the security policies to the Agile Controller. The Agile Controller then delivers such policies to agile switches that will handle security events accordingly. All these ensure campus network security.

Intelligent diagnosis

Open Intelligent Diagnosis System (OIDS) integrates the device health monitoring and fault diagnosis functions – that are typically deployed on a Network Management System (NMS) – into the switch software to implement intelligent diagnosis on a single switch. After OIDS is deployed on a switch, the switch periodically collects and records the running information and automatically determines whether a fault occurs. If a fault occurs, the switch automatically locates the fault or helps locate the fault. All these merits increase fault locating efficiency of O&M staff while improving device maintainability.

Huawei S12708 Switch Product Ordering Info

LE2BN66ED000 N66E DC assembly rack (eight 60A outputs, maximum 2,200W per output, 600 x 600 x 2,200 mm)
LE2BN66EA000 N66E AC assembly rack (four 16A outputs, maximum 2,500W per output, 600 x 600 x 2,200 mm)
ET1BS12704S0 S12704 Assembly Chassis
ET1BS12708S0 S12708 assembly chassis
ET1BS12710S0 S12710 assembly chassis
ET1BS12712S0 S12712 assembly chassis
ET1MFBX00000 Wide Voltage 129 Fan Box
EH1M00FBX000 Wide Voltage 74 Fan Box
Monitoring unit
EH1D200CMU00 Centralized monitoring unit
Main processing unit
ET1D2MPUA000 S12700 main control unit A, optional clock
ET1D2MPUBC00 S12710 main control unit B, optional clock
ET1D2MPUBC01 S12710,Main Processing Unit B (supports Secure Boot)
ET1D2MPUDC00 S12704/S12708/S12712, main processing unit D
Switch fabric unit
ET1D2SFUA000 S12700 switch fabric unit A
ET1D2SFUB000 S12700 switch fabric unit B
ET1D2SFUC000 S12700 switch fabric unit C
ET1D2SFUD000 S12700 switch fabric unit D
100M/1,000M Ethernet electrical interface cards
ET1D2G48TEA0 48-port 10/100/1,000 BASE-T interface card (EA, RJ45)
ET1D2G48TEC0 48-port 10/100/1,000 BASE-T interface card (EC, RJ45)
ET1D2G48TX1E 48-port 10/100/1,000 BASE-T interface card (X1E, RJ45)
ET1D2G48TX5S 48-port 100/1000BASE-T interface card (X5S, RJ45)
ET1D2G48TX5E 48-port 100/1000BASE-T interface card (X5E, RJ45)
ET1D2G48TX5H 48-port 100/1000BASE-T interface card (X5H, RJ45)
100M/1,000M Ethernet optical interface cards
ET1D2G24SEC0 24-port 100/1,000 BASE-X interface card (EC, SFP)
ET1D2G24SX5E 24-port 100/1000BASE-X interface card (X5E, SFP)
ET1D2G48SEA0 48-port 100/1,000 BASE-X interface card (EA, SFP)
ET1D2G48SEC0 48-port 100/1,000 BASE-X interface card (EC, SFP)
ET1D2G48SX1E 48-port 100/1,000 BASE-X interface card (X1E, SFP)
ET1D2G48SX5S 48-port 100/1000BASE-X interface card (X5S, SFP)
ET1D2G48SX5E 48-port 100/1000BASE-X interface card (X5E, SFP)
ET1D2G48SX5H 48-port 100/1000BASE-X interface card (X5H, SFP)
100M/1,000M Ethernet electrical and optical interface cards
ET1D2T36SEA0 36-port 10/100/1000 BASE-T and 12-port 100/1000 BASE-X interface card (EA, RJ45/SFP)
10 GE optical interface cards
ET1D2S04SX1E 4-port 10G BASE-X and 24-port 100/1000 BASE-X and 8-port 10/100/1000 BASE-T combo interface card (X1E, RJ45/SFP/SFP+)
ET1D2S04SX5E 4-port 10GE SFP+ and 44-port GE SFP interface card (X5E, SFP+)
ET1D2S08SX1E 8-port 10G BASE-X and 8-port 100/1000 BASE-X and 8-port 10/100/1000 BASE-T combo interface card (X1E, RJ45/SFP/SFP+)
ET1D2X08SX5E 8-port 10GE SFP+ interface card (X5E, SFP+)
ET1D2X08SX5H 8-port 10GE SFP+ interface card (X5H, SFP+)
ET1D2X16SSC2 16-Port 10GBASE-X Interface Card(SC, SFP+)
ET1D2X32SSC0 32-Port 10GBASE-X Interface Card(SC, SFP+)
ET1D2X48SEC0 48-port 10G BASE-X interface card (EC, SFP+)
ET1D2X32SX2H 32-Port 10GE SFP+ Interface Card(X2H, SFP+)
ET1D2X32SX2S 32-Port 10GE SFP+ Interface Card(X2S, SFP+)
ET1D2X32SX2E 32-Port 10GE SFP+ Interface Card(X2E, SFP+)
ET1D2S24SX2S 24-Port 10GE SFP+ Interface and 8-Port GE SFP Interface Card(X2S, SFP+)
ET1D2S24SX2E 24-Port 10GE SFP+ Interface and 8-Port GE SFP Interface Card(X2E, SFP+)
ET1D2S16SX2S 16-Port 10GE SFP+ Interface and 16-Port GE SFP Interface Card(X2S, SFP+)
ET1D2S16SX2E 16-Port 10GE SFP+ Interface and 16-Port GE SFP Interface Card(X2E, SFP+)
ET1D2X48SX2S 48-Port 10GE SFP+ Interface Card(X2S, SFP+)
40 GE optical interface cards
ET1D2L02QSC0 2-port 40G BASE-X interface card (SC, QSFP+)
ET1D2L08QSC0 8-port 40G BASE-X interface card (SC, QSFP+)
EH1D2L08QX2E 8-Port 40 GE QSFP+ Interface Card (X2E, QSFP+)
ET1D2L16QX2H 16-Port 40 GE QSFP+ Interface Card (X2H, QSFP+)
100 GE optical interface cards
ET1D2C02FEE0 2-Port 100G BASE-X Interface Card(EE,CFP)
ET1D2C04HX2H 4-Port 100 GE QSFP28 Interface Card (X2H, QSFP28)
ET1D2C04HX2S 4-Port 100 GE QSFP28 Interface Card (X2S, QSFP28)
ET1D2C04HX2E 4-Port 100 GE QSFP28 Interface Card (X2E, QSFP28)
ET1D2C08HX2H 8-Port 100 GE QSFP28 Interface Card (X2H, QSFP28)
ET1D2H02QX2S 2-Port 100 GE QSFP28 Interface and 2-Port 40 GE QSFP+ Interface Card (X2S, QSFP28)
ET1D2H02QX2E 2-Port 100 GE QSFP28 Interface and 2-Port 40 GE QSFP+ Interface Card (X2E, QSFP28)
Service subcards
EH1D2VS08000 8-port 10G cluster switching system service unit (SFP+)
ET1D2VQ06000 6-Port 40 GE Cluster Switching System Service Unit (QSFP+)
LE0D00CKMA00 Clock Pinch Board-1588
Service processing cards
ET1D2FW00S00 NGFW Module A, with HW General Security Platform Software
ET1D2FW00S01 NGFW Module B, with HW General Security Platform Software
ET1D2FW00S02 NGFW Module C, with HW General Security Platform Software
ET1D2IPS0S00 IPS Module A, with HW General Security Platform Software
ACU2 WLAN ACU2 Access Controller Unit (128 AP Control Resource Included)
Optical transceivers
FE-SFP optical transceiver
SFP-FE-SX-MM1310 Optical transceiver, SFP, 100M/155M, Multi-mode Module (1,310 nm, 2 km, LC)
eSFP-FE-LX-SM1310 Optical transceiver, eSFP, 100M/155M, Single-mode Module (1,310 nm, 15 km, LC)
S-SFP-FE-LH40-SM1310 Optical transceiver, eSFP, FE, single-mode module (1,310 nm, 40 km, LC)
S-SFP-FE-LH80-SM1550 Optical transceiver, eSFP, FE, single-mode module (1,550 nm, 80 km, LC)
GE-SFP optical transceiver
SFP-1000BaseT Copper transceiver, SFP, GE, electrical interface module (100m, RJ45)
eSFP-GE-SX-MM850 Optical transceiver, eSFP, GE, multimode module (850 nm, 0.5 km, LC)
SFP-GE-LX-SM1310 Optical transceiver, SFP, GE, single-mode module (1,310 nm, 10 km, LC)
S-SFP-GE-LH40-SM1310 Optical transceiver, eSFP, GE, single-mode module (1,310 nm, 40 km, LC)
S-SFP-GE-LH40-SM1550 Optical transceiver, eSFP, GE, single-mode module (1,550 nm, 40 km, LC)
S-SFP-GE-LH80-SM1550 Optical transceiver, eSFP, GE, single-mode module (1,550 nm, 80 km, LC)
eSFP-GE-ZX100-SM1550 Optical transceiver, eSFP, GE, single-mode module (1,550 nm, 100 km, LC)
10 GE-XFP Optical transceiver
XFP-SX-MM850 Optical transceiver, XFP, 10G, multimode module (850 nm, 0.3 km, LC)
XFP-STM64-LX-SM1310 Optical transceiver, XFP, 10G, single-mode module (1,310 nm, 10 km, LC)
XFP-STM64-LH40-SM1550 Optical transceiver, XFP, 10G, single-mode module (1,550 nm, 40 km, LC)
XFP-STM64-SM1550-80 km Optical transceiver, XFP, 10G, single-mode module (1,550 nm, 80 km, LC)
10 GE-SFP+ Optical transceiver
OMXD30000 Optical transceiver, SFP+, 10G, multimode module (850 nm, 0.3 km, LC)
OSX010000 Optical transceiver, SFP+, 10G, single-mode module (1,310 nm, 10 km, LC)
OSX040N01 Optical transceiver, SFP+, 10G, single-mode module (1,550 nm, 40 km, LC)
OSXD22N00 Optical transceiver, SFP+, 10G, single-mode module (1,310 nm, 0.22km, LC, LRM)
SFP-10G-USR Optical transceiver, SFP+, 10G, multimode module (850 nm, 0.1 km, LC)
SFP-10G-ZR Optical transceiver, SFP+, 10G, single-mode module (1,550 nm, 80 km, LC)
SFP-10G-ZCW1571 Optical transceiver, SFP+, 10G, single-mode module (CWDM, 1,571 nm, 70 km, LC)
SFP-10G-ZCW1591 Optical transceiver, SFP+, 10G, single-mode module (CWDM, 1,591 nm, 70 km, LC)
SFP-10G-ZCW1611 Optical transceiver, SFP+, 10G, single-mode module (CWDM, 1,611 nm, 70 km, LC)
SFP-10G-iLR Optical transceiver, SFP+, 10G, single-mode module (DWDM, 1560.61–1529.16nm, 60km, LC)
SFP-10G-ZDWT-L Optical Transceiver, SFP+, 9.8G, Single-mode Module (1,310 nm, 1.4 km, LC)
40 GE optical transceivers
QSFP-40G-iSR4 40G Base-iSR4 Optical transceiver, QSFP, 40G, multimode module (850 nm, 0.15 km, MPO) (connecting to four SFP+ optical transceivers)
QSFP-40G-LX4 40G Base-LX4 Optical Transceiver, QSFP+, 40 GE, Single-mode (1,310 nm, 2 km, LC), Multi-mode (1,310 nm, 0.15 km, LC)
QSFP-40G-iSM4 40G Base-iSM4 Optical Transceiver, QSFP+, 40G, Single-mode Module (1,310 nm, 1.4 km, MPO) (connecting to four SFP+ optical transceivers)
QSFP-40G-eSM4 40G Base-eSM4 Optical Transceiver, QSFP+, 40G, Single-mode Module (,1310 nm, 10 km, MPO) (connecting to four SFP+ optical transceivers)
QSFP-40G-LR4 40G Base-LR4 optical transceiver, QSFP+, 40G, single-mode module (1,310 nm, 10 km, LC)
QSFP-40G-eSR4 40G Base-eSR4 Optical transceiver, QSFP+, 40G, multimode module (850 nm, 0.3 km, MPO) (connecting to four SFP+ optical transceivers)
CFP-40G-SR4 High-Speed Transceiver, CFP, 40G, Multimode Module (850 nm, 4 x 10G, 0.1 km, MPO)
CFP-40G-LR4 High-Speed Transceiver, CFP, 40G, Single-mode Module (1,310 nm band, 41.25G, 10 km, stright LC)
CFP-40G-ER4 High-Speed Transceiver, CFP, 40G, Single-mode Module (1,310 nm band, 41.25G, 40 km, stright LC)
CFP-40G-ZR4 High-Speed Transceiver, CFP,40G, Single-mode Module (1,550 nm band, 41.25G, 80 km, stright LC)
QSFP-40G-ER4 40G Base-ER4 Optical Transceiver, QSFP+, 40G, Single-mode Module (1,310 nm, 40 km, LC)
100 GE optical transceivers
CFP-100G-SR10 High-Speed Transceiver, CFP, 100G, Multimode Module (850 nm, 10 x 10G, 0.1 km, MPO) (can connect to 10 SFP+ ports or 2 QSFP+ ports)
CFP-100G-LR4 High-Speed Transceiver, CFP, 100G, Single-mode Module (1,310 nm band, 4 x 25G, 10 km, stright LC)
CFP-100G-ER4 High-Speed Transceiver, CFP, 100G, Single-mode Module (1,310 nm band, 4 x 25G, 40 km, stright LC)
CFP-100GE-ZR4 100G Base,CFP Module, 100G, Single-mode Module (1,310 nm band, 4 x 25G, 80 km, stright LC)
QSFP-100G-CLR4 High-Speed Transceiver, QSFP28, 1,310 nm, 4 x 25G Base, -6.5 dBm, 2.5 dBm, -10.7 dBm, LC/PC, 2 km
QSFP-100G-CWDM4 High-Speed Transceiver, QSFP28, 1,310 nm, 4 x 25G Base, -6.5 dBm, 2.5 dBm, -9.8 dBm, LC/PC, 2 km
QSFP-100G-ER4-Lite 100G Base-ER4-Lite Optical Transceiver, QSFP28, 100G, Single-mode module (1,310 nm, 30 km (FEC OFF), 40 km (FEC ON), LC)
QSFP-100G-LR4 100G Base-LR4 Optical Transceiver, QSFP28, 100G, Single-mode module (1,310 nm, 10 km, LC)
QSFP-100G-SR4 100G Base-SR4 Optical Transceiver, QSFP28, 100G, Multi-mode (850 nm, 0.1 km, MPO)
QSFP-100G-PSM4 100G Base-PSM4 Optical Transceiver, QSFP28, 100G, Single-mode module (1,310 nm, 0.5 km, MPO)
BIDI-SFP optical transceivers
SFP-FE-LX-SM1310-BIDI Optical transceiver, eSFP, FE, BIDI single-mode module (TX1310/RX1550, 15 km, LC)
SFP-FE-LX-SM1550-BIDI Optical transceiver, eSFP, FE, BIDI single-mode module (TX1550/RX1310, 15 km, LC)
SFP-GE-LX-SM1310-BIDI Optical transceiver, eSFP, GE, BIDI single-mode module (TX1310/RX1490,10 km, LC)
SFP-GE-LX-SM1490-BIDI Optical transceiver, eSFP, GE, BIDI single-mode module (TX1490/RX1310,10 km, LC)
LE2MGSC40ED0 Optical transceiver, SFP, GE, BIDI single-mode module (TX1490/RX1310, 40 km, LC)
LE2MGSC40DE0 Optical transceiver, SFP, GE, BIDI single-mode module (TX1310/RX1490, 40 km, LC)
SFP-GE-ZBXD1 Optical Transceiver, eSFP, GE, BIDI Single-mode Module (TX1570/RX1490, 80 km, LC)
SFP-GE-ZBXU1 Optical Transceiver, eSFP, GE, BIDI Single-mode Module (TX1490/RX1570, 80 km, LC)
BIDI-SFP+ optical transceivers
SFP-10G-ER-SM1330-BIDI Optical Transceiver, SFP+, 10G, BIDI Single-mode Module (TX1330/RX1270, 40 km, LC)
SFP-10G-ER-SM1270-BIDI Optical Transceiver, SFP+, 10G, BIDI Single-mode Module (TX1270/RX1330, 40 km, LC)
SFP-10G-BXU1 10G Base, Bi-Directional (BIDI) optical transceiver, SFP, 10G, single-mode module (TX1270/RX1330, 10 km, LC)
SFP-10G-BXD1 10G Base, BIDI optical transceiver, SFP, 10G, single-mode module (TX1330/RX1270, 10 km, LC)
High-Speed Cable
SFP-10G-CU1M SFP+,10G, High-Speed Direct-attach Cables, 1m, SFP + 20M, CC2P0.254B(S), SFP + 20M, used indoors
SFP-10G-CU3M SFP+, 10G, High-Speed Direct-attach Cables, 3m, SFP + 20M, CC2P0.254B(S), SFP + 20M, used indoors
SFP-10G-CU5M SFP, 10G, High-Speed Cable, 5m, SFP + 20M, CC2P0.254B(S), SFP + 20M, LSFRZH for indoors
SFP-10G-AC10M SFP+, 10G, Active High-Speed Cables, 10m, SFP + 20M, CC2P0.32B(S), SFP + 20M, used indoors
QSFP-4SFP10G-CU1M QSFP+, 4SFP + 10G, High-Speed Direct-attach Cables, 1m, QSFP + 38M, CC8P0.254B(S), 4 x SFP + 20M, used indoors
QSFP-4SFP10G-CU3M QSFP+, 4SFP + 10G, High-Speed Direct-attach Cables, 3m, QSFP + 38M, CC8P0.32B(S), 4 x SFP + 20M, used indoors
QSFP-4SFP10G-CU5M QSFP+, 4SFP + 10G, High-Speed Direct-attach Cables, 5m, QSFP + 38M, CC8P0.4B(S), 4 x SFP + 20M, used indoors
QSFP-40G-CU1M QSFP+, 40G, High-Speed Direct-attach Cables, 1m, QSFP + 38M, CC8P0.254B(S), QSFP + 38M, used indoors
QSFP-40G-CU3M QSFP+, 40G, High-Speed Direct-attach Cables, 3m, QSFP + 38M, CC8P0.32B(S), QSFP + 38M, used indoors
QSFP-40G-CU5M QSFP+, 40G, High-Speed Direct-attach Cables, 5m, QSFP + 38M, CC8P0.40B(S), QSFP + 38M, used indoors
QSFP-100G-CU1M High-Speed Cable, 100G QSFP28 Passive High-Speed Cable, 1m, QSFP28, CC8P0.254B(S), QSFP28, ETH 100 GbE
QSFP-100G-CU3M High-Speed Cable, 100G QSFP28 Passive High-Speed Cable, 3m, QSFP28, CC8P0.254B(S), QSFP28, ETH 100 GbE
QSFP-100G-CU5M High-Speed Cable, 100G QSFP28 Passive High-Speed Cable, 5m, QSFP28, CC8P0.4B(S), QSFP28, ETH 100 GbE
Optical Fiber
SFP-10G-AOC3M AOC Optical Transceiver, SFP+, 850 nm, 1G to 10G, 0.003 km
SFP-10G-AOC10M AOC Optical Transceiver, SFP+, 850 nm, 1G to 10G, 10m
QSFP-H40G-AOC10M Optical transceiver, QSFP+, 40G, (850 nm, 10m, AOC)
QSFP-4SFP10-AOC10M Optical transceiver, QSFP+, 40G, (850 nm, 10m, AOC) (connecting to four SFP+ optical transceivers)
QSFP-100G-AOC10M High-Speed Transceiver, QSFP28 to QSFP28 AOC, 850 nm, 100G, 0.01 km
Power modules
PAC-2200WF 2,200W AC power module
PDC-2200WF 2,200W DC power module
W2PSA0800 800W AC Power Module (black)
Software
ET1SBSM28000 S12700 V200R008C00 software
ET1SBSM2A000 S12700 V200R010C00 software
ET1SBSM2B010 S12700 V200R011C10 software
ET1SBSM2C000 S12700 V200R012C00 software
ET1SBSM2D000 S12700 V200R013C00 Mainframe Software
License
ET1SMPLS0000 MPLS Function License
ET1SNQA00000 NQA Function License
ET1SIPV60000 IPV6 Function License
ET1SSVFF0000 SVF Function License (applicable only to the S12700 series)
ET1SVXLAN000 VXLAN enhanced function license(used in S12700 series)
ET1SFIB128K0 X-series LPU FIB Resource License-128K
ET1SFIB512K0 X-series LPU FIB Resource License-512K
ET1SWL512AP0 WLAN Access Controller AP Resource License-512AP (with the X-series LPU used)
ET1SWL128AP0 WLAN Access Controller AP Resource License-128AP (with the X-series LPU used)
ET1SWL64AP00 WLAN Access Controller AP Resource License-64AP (with the X-series LPU used)
ET1SWL16AP00 WLAN Access Controller AP Resource License-16AP (with the X-series LPU used)
L-ACU2-128AP ACU2 Wireless Access Controller AP Resource License (128 AP)
L-ACU2-256AP ACU2 Wireless Access Controller AP Resource License (256 AP)
L-ACU2-384AP ACU2 Wireless Access Controller AP Resource License (384 AP)
L-ACU2-512AP ACU2 Wireless Access Controller AP Resource License (512 AP)
Documentation
ET1IV2RDC0E0 S12700 Series Agile Switches V200R013C00 Product Documentation

Huawei S12708 Switch Product Applications

Huawei CE2808S Switch price and specs ce12800 ycict
