Huawei S5730-48C-SI-AC Switch is a next-generation standard gigabit Layer 3 Ethernet switch with 24*10/100/1000 Ethernet ports, 8 10GE SFP+ ports and One 150 W AC power supply equipped by default

Huawei S5730-48C-SI-AC Switch Product Overview

The switch stands out with One interface slot, forwarding performance, 240 Mpps and Switching capacity: 680 Gbit/s. The S5730-SI builds on next-generation high performing hardware and the Huawei Versatile Routing Platform (VRP). It supports simplified operations and maintenance (O&M), intelligent stack (iStack), and flexible Ethernet networking. In addition, Huawei S5730-48C-SI-AC also provides enhanced Layer 3 features and mature IPv6 features. Based on these merits, this model can be used in various scenarios. For example, it can be used as an access or aggregation switch on a campus network or as an access switch in a data center.

Huawei S5730-48C-SI-AC Switch Product Pictures

Huawei S5730-48C-SI-AC specs S5730 series price and specs ycictHuawei S5730-48C-SI-AC specs huawei switch new and original ycict

S5736-S Series All-Optical Switches ycictHuawei S5700-52X-LI-AC Switch huawei s5700 switch ycict

Huawei S5730-48C-SI-AC Switch Product Specifications

Model S5730-48C-SI-AC
Switching Capacity 680 Gbit/s
Forwarding Performance 240 Mpps
Fixed Ports 24 x 10/100/1,000 Base-T, 8 x 10 Gigabit SFP+
Extended Slots One extended slot that supports an interface card: 4 x 40 GE QSFP+ interface card
IP Routing Static route, RIPv1/v2, RIPng, OSPF, OSPFv3, ECMP, IS-IS, IS-ISv6, BGP, BGP4+, VRRP, and VRRP6
Interoperability VLAN-Based Spanning Tree (VBST) (interoperating with PVST, PVST+, and RPVST)
Link-type Negotiation Protocol (LNP) (similar to DTP)
VLAN Central Management Protocol (VCMP) (similar to VTP)
MAC Address Table 32K
MAC address learning and aging
Static, dynamic, and blackhole MAC address entries
Packet filtering based on source MAC addresses
VLAN Features 4,094 VLANs
Guest VLAN, Voice VLAN
VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports
1:1 and N:1 VLAN mapping

Huawei S5730-48C-SI-AC Switch Product Features

  • Support many Layer 2/Layer 3 multicast protocols such as PIM SM, PIM DM, PIM SSM, MLD, and IGMP snooping, to support multi-terminal high-definition video surveillance and video conferencing services.
  • Support multiple Layer 3 features including OSPF, IS-IS, BGP, and VRRP, meeting enterprises’ requirements on access and aggregation service transmission and enabling a variety of voice, video, and data applications.
  • Support MAC address authentication, 802. 1X authentication, and Portal authentication, and implements dynamic delivery of policies (VLAN, QoS, and ACL) to users.
  • Provide a series of mechanisms to defend against DoS and user-targeted attacks. DoS attacks are targeted at switches and include SYN flood, Land, Smurf, and ICMP flood attacks. User-targeted attacks include bogus DHCP server attacks, IP/MAC address spoofing, DHCP request flood, and change of the DHCP CHADDR value.

Huawei S5730-48C-SI-AC Switch and More S5730 Models


Huawei S5730-48C-SI-AC Switch Product Applications
