Description
Huawei S5735-L8P2T4X-A-V2 Switch is a simplified gigabit Ethernet switch with 8 x 10/100/1000Base-T ports(PoE+), 2 x 10/100/1000Base-T ports, 4 x 10 GE SFP+ ports and Built-in AC
Huawei S5735-L8P2T4X-A-V2 Switch Product Overview
The switch provides Forwarding performance: 75 Mpps and Switching capacity: 100 Gbps/520 Gbps. S5735-L-V2 supports intelligent stack (iStack). This technology combines multiple switches into a logical switch. Member switches in a stack implement redundancy backup to improve device reliability and use inter-device link aggregation to improve link reliability. Moreover, CloudEngine S5735-L-V2 supports Open Programmability System (OPS), an open programmable system based on the Python language. IT administrators can program the O&M functions of a CloudEngine S5735-L-V2 switch through Python scripts to quickly innovate functions and implement intelligent O&M. Based on the next-generation high-performance hardware and Huawei’s unified software platform, Huawei S5735-L8P2T4X-A-V2 is ideal for various industries, such as healthcare, retail, mining, and Internet.
Huawei S5735-L8P2T4X-A-V2 Switch Product Pictures
Huawei S5735-L8P2T4X-A-V2 Switch Product Specifications
| Product Model | CloudEngine S5735-L10T4X-A-V2 | CloudEngine S5735-L10T4X-TA-V2 | CloudEngine S5735-L8P2T4X-A-V2 | CloudEngine S5735-L8P2T4X-TA-V2 |
| Forwarding Performance | 75Mpps | 75Mpps | 75Mpps | 75Mpps |
| Switching Capacity2 | 100Gbps/520Gbps | 100Gbps/520Gbps | 100Gbps/520Gbps | 100Gbps/520Gbps |
| Fixed Ports | 10 x 10/100/1000BASE-T ports, 4 x 10 GE SFP+ ports | 10 x 10/100/1000BASE-T ports, 4 x 10 GE SFP+ ports | 8 x 10/100/1000BASE-T ports(PoE+), 2 x 10/100/1000BASE-T ports,4 x 10 GE SFP+ ports | 8 x 10/100/1000BASE-T ports(PoE+), 2 x 10/100/1000BASE-T ports,4 x 10 GE SFP+ ports |
| PoE | Not supported | Not supported | Supported | Supported |
| MAC Features | MAC address auto-learning and aging | |||
| Static, dynamic, and blackhole MAC address entries | ||||
| Packet filtering based on source MAC addresses | ||||
| Interface-based MAC address learning limiting | ||||
| VLAN Features | 4094 VLANs | |||
| Voice VLAN | ||||
| MUX VLAN | ||||
| VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports | ||||
| IP Routing | Static route, RIPv1/v2, RIPng, OSPF, OSPFv3 | |||
| Interoperability | VBST (compatible with PVST/PVST+/RPVST) | |||
| LNP (similar to DTP) | ||||
Huawei S5735-L8P2T4X-A-V2 Switch Product Features
- S5735-L-V2 supports the intelligent upgrade feature. Specifically, CloudEngine S5735-L-V2 obtains the version upgrade path and downloads the newest version for upgrade from the Huawei Online Upgrade Platform (HOUP). The entire upgrade process is highly automated and achieves one-click upgrade. In addition, preloading the version is supported, which greatly shortens the upgrade time and service interruption time.
- S5735-L-V2 supports intelligent stack (iStack). This technology combines multiple switches into a logical switch. Member switches in a stack implement redundancy backup to improve device reliability and use inter-device link aggregation to improve link reliability.
- S5735-L-V2 supports Open Programmability System (OPS), an open programmable system based on the Python language. IT administrators can program the O&M functions of a CloudEngine S5735-L-V2 switch through Python scripts to quickly innovate functions and implement intelligent O&M.
Huawei S5735-L8P2T4X-A-V2 Switch and More Models
CloudEngine S5735-L8T4S-A-V2 8×10/100/1000Base-T ports, 4xGE SFP ports Built-in AC
CloudEngine S5735-L8P4S-A-V2 8×10/100/1000Base-T ports, 4 x GE SFP ports Built-in AC PoE+
CloudEngine S5735-L10T4X-A-V2 10×10/100/1000Base-T ports, 4 x 10 GE SFP+ ports Built-in AC
CloudEngine S5735-L8P2T4X-A-V2 8×10/100/1000Base-T ports(PoE+), 2×10/100/1000Base-T ports, 4×10 GE SFP+ ports Built-in AC
CloudEngine S5735-L10T4X-TA-V2 10×10/100/1000Base-T ports, 4×10 GE SFP+ ports Built-in AC
CloudEngine S5735-L8P2T4X-TA-V2 8×10/100/1000Base-T ports (PoE+), 2×10/100/1000Base-T ports, 4×10 GE SFP+ ports Built-in AC
CloudEngine S5735-L16T4S-A-V2 16×10/100/1000Base-T ports, 4xGE SFP ports Built-in AC
CloudEngine S5735-L24T4S-A-V2 24×10/100/1000Base-T ports, 4xGE SFP ports Built-in AC
CloudEngine S5735-L24P4S-A-V2 24×10/100/1000Base-T ports, 4xGE SFP ports Built-in AC PoE+
CloudEngine S5735-L24T4XE-A-V2 24×10/100/1000Base-T ports, 4×10 GE SFP+ ports, 2 stack ports Built-in AC
CloudEngine S5735-L24T4XE-D-V2 24×10/100/1000Base-T ports, 4x10GE SFP+ ports, 2x12GE stack ports Built-in DC
CloudEngine S5735-L24P4XE-A-V2 24×10/100/1000Base-T ports, 4x10GE SFP+ ports, 2x12GE stack ports Built-in AC PoE+
CloudEngine S5735-L24P4XE-TAV2 24×10/100/1000Base-T ports, 4x10GE SFP+ ports, 2x12GE stack ports Built-in AC PoE+
CloudEngine S5735-L48T4S-A-V2 48×10/100/1000Base-T ports, 4xGE SFP ports Built-in AC
CloudEngine S5735-L48LP4S-A-V2 48×10/100/1000Base-T ports, 4xGE SFP ports Built-in AC PoE+
CloudEngine S5735-L48T4XE-A-V2 48 x 10/100/1000Base-T ports, 4 x 10 GE SFP+ ports, 2 x12GE stack ports Built-in AC
CloudEngine S5735-L48T4XE-TAV2 48×10/100/1000Base-T ports, 4×10 GE SFP+ ports, 2x12GE stack ports Built-in AC
CloudEngine S5735-L48T4XE-D-V2 48×10/100/1000Base-T ports, 4×10 GE SFP+ ports, 2x12GE stack ports Built-in DC
CloudEngine S5735-L48P4XE-A-V2 48×10/100/1000Base-T ports, 4×10 GE SFP+ ports, 2x12GE stack ports Built-in AC PoE+
CloudEngine S5735-L48LP4XE-AV2 48×10/100/1000Base-T ports, 4×10 GE SFP+ ports, 2x12GE stack ports Built-in AC PoE+
Huawei S5735-L8P2T4X-A-V2 Switch Product Applications
