SC/UPC duplex adapter is SC/UPC to SC/UPC Duplex Single Mode Plastic Fiber Optic Adapter/Coupler with Flange

SC/UPC duplex adapter Overview

A fiber optic adapter (coupler) is a small device designed to terminate or link the fiber optic cables or fiber optic connectors between two fiber optic lines.

When connecting two multimode fibers, you should always make sure they are the same core diameter (50/125 or 62.5/125). A mismatch here will cause attenuation in one direction (where the larger fiber is transmitting light into the smaller fiber).

By linking two connectors precisely, fiber optic adapters allow the light sources to be transmitted at most and lower the loss as much as possible. At the same time, fiber optic adapters have the merits of low insertion loss, good interchangeability and reproducibility

SC/UPC duplex adapter Product Pictures

Fiber Optic Adapter price and specs ycictSC UPC adaptor specs Network Accessories Fiber Optic Patch Cables Connector Adaptor

SC UPC adaptor specs Plastic Fiber Optic Adapter/Coupler with FlangeSC UPC adapter blue Plastic Fiber Optic Adapter/Coupler

SC/UPC duplex adapter Specifications

Connector Type SC-SC
Body Style Duplex
Polish Type UPC
Fiber Mode OS2 9/125μm
Insertion Loss ≤0.2dB
Durability 1000 times
Mounting Type Full flanged
Alignment Sleeve Material Ceramic
Color Blue
Flammability Rate UL94-V0
Package Quantity 10
RoHS Compliancy Status Compliant

SC/UPC duplex adapter Features

  • Simplex and duplex panel cutouts
  • Panel clip for easy installation
  • Increase panel density and quick plug in installation
  • Operating temperature: -40°C ~ 85°C
  • Durability (500 Mating): 0.2dB Max Increase

SC/UPC duplex adapter Applications


SC/UPC duplex adaptor good price
