Cisco NCS 5064 Router


Cisco NCS 5064 Router is a Two-Rack-Unit (2RU) fixed form-factor, dense 10GE/25GE/40GE/50GE*/100GE system,

This model is powered by industry-leading Cisco IOS® XR Software, offering rich functions like third-party application hosting, telemetry, and flexible package delivery.

Cisco NCS 5064 Router introduces MACsec to the NCS 5000 family, offering 16 ports of MACsec.

Cisco NCS 5064 Router is high-performance, power-efficient, 100-Gbps router design. This 2RU model offers line-rate throughput on all ports and supports both forward (port-side exhaust) and reverse (port-side intake) airflow schemes with AC and DC power inputs.

Cisco NCS 5064 Router Product Picture

Cisco NCS 5064 RouterCisco NCS 5064 Router

Cisco NCS 5064 RouterCisco NCS 5064 Router

Cisco NCS 5064 Router Datasheet

Integrated interfaces64 ports of 100 GE
64 ports of 40 GE
64 ports of 25 GE
64 ports of 10GE
Ports 0-15 support dynamic breakout with 4x10G, 4x25G, and 2x50G combinations
PerformanceUp to 6.4 Tbps throughput
Storage256 GB M2 SSD
Memory128 GB DDR4
Physical specificationsHeight: 3.5 in (8.89 cm)
Width: 17.3 in (43.94 cm)
Depth: 23.4 in (59.43 cm)
Weight of chassis: 34.82 lb (15.79 kg)
Power inputsWorldwide ranging AC (100–240V)
Worldwide ranging DC (–48V to – 60V)
Power consumptionTypical: 392W
Maximum: 1263W
Operating temperature (nominal)5°C to 45°C
Operating temperature (short term)–5°C to 55°C
Operating humidity (nominal) (relative humidity)5% to 85% noncondensing
Operating humidity (short term)5% to 93% but not to exceed 0.026 kg water/kg of dry air
Storage temperature–40°C to 70°C
Storage (relative humidity)93% at 40°C per NEBS GR-63-Core
Operating altitudeUp to 1829 m (6000 ft) at 55°C
1829 m (6000 ft) to 3960 m (13,000 ft) at 45°C
Air flowFront to back
Back to front
Network Equipment Building Standards (NEBS)SR-3580 NEBS level 3
(GR-63-CORE to current issue, GR-1089-CORE to current issue)
ETSIETSI 300-019 requirements are covered under GR-63-CORE with some deviations

Cisco NCS 5064 Router Benefits

High performance, low power use

The 5000 Series routers offer 960-Gbps throughput with 1.4 Bpps. They also have a small footprint and consume less power.

Network virtualization

Cisco nV technology dramatically reduces operational costs and simplifies the network through the use of the Cisco ASR 9000 Series distributed control plane.

Optimized for cloud scale

Get a dense, programmable solution that supports application hosting, machine-to-machine (M2M) interfacing, telemetry, and flexible package delivery for software feature enhancements

Cisco NCS 5064 Router Applications

Cisco NCS 5064 Router
